2D & 3D Machine Guidance
Digmaster Pro

Class leading 2D & 3D machine guidance delivered by KINSHOFER Prolec's Digmaster Pro

Suitable for

  • Excavators - multiple articulations

Benefits

  • Superior display for ease of use and personalisation
  • Icon driven menu allows use in any language and without extensive training
  • Industrial benchmark for speed of operation and response
  • Productivity gains in double digits through efficiency and removal of waste
  • Consistency of operation regardless of skill level

Features

  • Switch between 2D and 3D as needed (GNSS system required)
  • Icon driven menu with customisable favourites
  • Familiar Windows™ operating system
  • Pan/zoom and rotate feature for improved visibility of work area
  • Fully removable touch screen computer can be transported between multiple excavators
  • Display monitors bucket position precisely in real time
  • Progress maps in multiple colours allows easy review of work progress
  • On target indicators through graphics and colour coding
  • Multiple tool point positions for precision grading
  • Unlimited bucket and special tool designs available (see Prolec for complex tools)
  • Configurable auto zoom and “rainbow” bucket features
  • Configurable deadband and cross hairs displayed when digging
  • Configurable data shown on display – distance to target, depth etc.
  • Configurable views allowing multiple views of one job
  • Configurable slew monitor status indicator
  • Configurable avoidance zones, chain age lines and POI (can be exported from works also)
  • Pro Job software allowing import and export of multiple file formats
  • Simple GNSS monitor displays status of the positioning signal
  • Context specific help

Options

  • 2D or 3D Operation

Digmaster Pro is a superior concept in machine control for excavators that allows operators to work in 3D when required and move to 2D for less demanding applications. In 2D mode the system works to a known reference, while in 3D mode, the system allows a surveyed design known as a Digital Terrain Map (DTM) to be uploaded into the cab. Using Digmaster Pro in 3D mode, grade control to accuracies of 2cm can be achieved anywhere within the digital terrain map. The system allows skilled operators to be more efficient and less skilled operators to achieve productivity going beyond their expectations.

Head line machine guidance benefits
  • Increase productivity by 50%
  • Reduce staking by up to 90%
  • Complete jobs faster and improve accuracy
  • Reduces staff around the machine
  • Reduces fuel consumption
  • Reduces material overage & transportation costs
  • Minimise environmental foot print
  • Ensures consistency of operations regardless of operator skill level

Pro Job - desktop editing suite


Pro Job is KINSHOFER Prolec's proprietary desktop editing suite.  It converts the designers file into a Prolec format called a '.tri' file.

Main benefits



  • Allows Digmaster Pro to work on a single file format
  • Pro Job can evolve without affecting Digmaster Pro



Files contain but not limited to, the following features



  • Multiple Target layers
  • Multiple overlay
  • Multiple chainage lines
  • Three types of avoidance zones available
